ARAG -

编码	A	Assorbimento @ 12 V	B	C	Connessione	D	DN	E	G	L	On / Off @ 90°	Pressione MAX	S	Tensione di alimentazione	X	Y	流量 @ 0,5bar - 7PSI	球
853R14A44	101mm	3 A	42mm	171mm	SWITCH ON-OFF	98mm	25mm	102mm	52mm	23mm	1.4 s	12bar	50mm	12 VDC	33mm	38mm	200l/min	UHMW BALL
853R14A55	105mm	3 A	42mm	171mm	SWITCH ON-OFF	98mm	32mm	102mm	58mm	25mm	1.4 s	12bar	50mm	12 VDC	33mm	38mm	270l/min	UHMW BALL
853R15A66	128mm	3 A	52mm	178mm	SWITCH ON-OFF	98mm	40mm	102mm	63mm	25mm	2.3 s	10bar	50mm	12 VDC	40mm	49mm	540l/min	UHMW BALL
853R16A77	150mm	3 A	61mm	187mm	SWITCH ON-OFF	98mm	50mm	102mm	73mm	28mm	2.3 s	8bar	50mm	12 VDC	57mm	60mm	650l/min	UHMW BALL
853R17A88	168mm	3 A	71mm	200mm	SWITCH ON-OFF	98mm	65mm	102mm	88mm	33mm	2.3 s	6bar	50mm	12 VDC	72mm	80mm	1050l/min	UHMW BALL
853R17A99	174mm	3 A	71mm	200mm	SWITCH ON-OFF	98mm	65mm	102mm	94mm	36mm	2.3 s	6bar	50mm	12 VDC	72mm	80mm	1050l/min	UHMW BALL
853T14A44	101mm	3 A	42mm	171mm	SWITCH ON-OFF	98mm	25mm	102mm	52mm	23mm	1.4 s	12bar	50mm	12 VDC	33mm	38mm	200l/min	AISI 316 BALL
853T14A55	105mm	3 A	42mm	171mm	SWITCH ON-OFF	98mm	32mm	102mm	58mm	25mm	1.4 s	12bar	50mm	12 VDC	33mm	38mm	270l/min	AISI 316 BALL
853T15A66	128mm	3 A	52mm	178mm	SWITCH ON-OFF	98mm	40mm	102mm	63mm	25mm	2.3 s	10bar	50mm	12 VDC	40mm	49mm	540l/min	AISI 316 BALL
853T16A77	150mm	3 A	61mm	187mm	SWITCH ON-OFF	98mm	50mm	102mm	73mm	28mm	2.3 s	8bar	50mm	12 VDC	57mm	60mm	650l/min	AISI 316 BALL
853T17A88	168mm	3 A	71mm	200mm	SWITCH ON-OFF	98mm	65mm	102mm	88mm	33mm	2.3 s	6bar	50mm	12 VDC	72mm	80mm	1050l/min	AISI 316 BALL
853T17A99	174mm	3 A	71mm	200mm	SWITCH ON-OFF	98mm	65mm	102mm	94mm	36mm	2.3 s	6bar	50mm	12 VDC	72mm	80mm	1050l/min	AISI 316 BALL

853 #853R15A66
